PUC2 Mic LEA – Real-Time Audio Processing

Product

Choose the PUC2 Mic LEA USB Audio Interface to get perfect audio levels with your favored XLR-microphone. Thanks to its onboard LEA Level Energy Arbitration, PUC2 Mic LEA delivers perfectly leveled recordings. You don’t need any time-consuming post-processing. LEA provides you with real-time audio processing and captures perfect levels without any clipping. PUC2 Mic LEA overcomes the problems of noisy recording environments and prevents any over- and under-loading.

PUC2 Mic LEA integrates the real-time LEA DSP Engine from Yellowtec’s iXm Recording Mic into a class-leading USB audio interface. Featuring one of the highest-quality mic preamps available, PUC2 Mic LEA ensures pristine audio quality with zero latency for your microphone signal. Use it to stream two channels of mic recordings via USB or use it as a standalone A/D converter with its preamp and LEA Level Energy Arbitration.

Features

• High-definition USB Audio Interface to optimize your audio quality
• Get perfectly leveled recordings without any post-processing
• Designed for recordings by podcasters + journalists + commentators
• Integrates the iXm Recording Mic’s LEA Level Energy Arbitration
• Stream two channels of XLR-mic recordings via USB
• Plug’n’play concept allows for fast handling
• Alternatively use it as a standalone A/D converter/preamp
• Delivers highest available audio standards
• 192kHz sample rate at 24-bit word-lengths

• Dynamic range of 114dB

• Zero latency for your mic signal + zero-latency monitoring

• Digital inputs and outputs
•
Cannot be used without the included PSU!
• AES-3 input + output on XLR

• 3.5mm socket to configure zero-latency monitoring
• ASIO driver for advanced operators
• Sturdy aluminum unibody serves as a conductor + heat sink
• Dimensions: 18.5 x 12.7 x 4.5cm | Weight: 0.6kg
• Additional PUC2 Wall Chargers are available as spare parts

Specs

• Power < 1000 mA via dual USB + PSU
• Clocking < 15 mUI Peak
• +/- 10 ppm
• Input selection Automatic with AES Detection
• Digital input AES 3 + SPF/DIF
• XLR 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
• 24 Bit
• Digital output AES 3 + SPF/DIF
• XLR
• 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
• 24 Bit
• Analog input -∞ … +18dBu
• Mic typ 1.2 kOhm
• Live typ 10 kOhm
• Analog output Not balanced
• Adjustable Volume
• < 16 Ohm,
• Headphones with up to 600 Ohm can be used
• USB USB 2.0 Type B
• Phantom power 48 V
• Headphone out Adjustable Volume
• < 16 Ohm,
• Headphones with up to 600 Ohm can be used
• Microphone input 0.05%
• -127 dBu @ 150 Ohm
• 1.2 kOhm
• A/D D/A converter 108 dB
• -107 dB THD+N
• -103 dB THD+N
• 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4kHz, 192 kHz
• 24 Bit
