HyperDeck ISO Recorder 100G

HyperDeck ISO Recorder 100G

HyperDeck ISO Recorder 100G is designed for live production, recording 8 cameras at the same time. Record for later editing or get exciting live-action replay with DaVinci Resolve! Files are recorded in broadcast-quality ProRes format direct to network storage for very long record durations. It connects via SMPTE-2110 100G Ethernet, so all 8 video channels run over a single connection. Or add a Blackmagic SDI Expander 8x12G for 12G-SDI. You can also play back all 8 channels, great for testing!

Ominaisuudet

• 100G 2110 IP Networks: 2 x 100G QSFP28 connections. Supports ST 2022-7 redundant delivery of IP streams over two 2110 networks.
• Senders and Receivers per 100G Pair: 8 x Ultra HD or 8 HD
• 100G Ethernet: 2 x 100G QSFP28 connections.
• 10G Control Network: 2 x 10G RJ45 Ethernet for NMOS control.
• Reference Network: 2 x RJ45 Ethernet for 2110 PTP clock.
• 1G Management: 1 x RJ45 Ethernet. Supports 10/100/1000 BASE-T. For HyperDeck Setup utility and software updates.
• SDI Monitor Outputs: 2
• HDMI Monitor Outputs: 1
• SDI Rates: 1.5G, 3G, 6G, 12G.
• Analog Audio Outputs: 1 x 6.35 mm headphone jack.
• SMPTE ST 2110 IP Audio Inputs: Up to 64 Ch embedded audio on each 2110 IP video stream over 100G Ethernet.
• SMPTE ST 2110 IP Audio Outputs: Up to 64 Ch embedded audio on each 2110 IP video stream over 100G Ethernet.
• SDI Audio Outputs: 16 channels embedded audio.
• HDMI Audio Outputs: 8 channels embedded audio.
• Computer Interface: 1 x USB-C for HyperDeck Setup utility and software updates.
• Power2 x IEC C14 power inputs.

Paketissa

• HyperDeck ISO Recorder 100G
• Welcome wallet with QR code for software download
